Product information table
Serial number | Name | Specification Type | Quantity | Remarks |
1 | Body | 245*105*220 | 1 unit | Material :304 stainless steel, thickened, high compression |
2 | Rehydration box | 150*85*50 | 1 unit | Material :304 stainless steel, thickened, high compression |
3 | PLC Control Screen | TG865-NT | 1 unit | TFT LCD, LED backlight |
4 | Filling machine filling head | Φ24 | 8 | Material: Bo Rui DC anti-drop leakage |
5 | Conveyor belt | DL-B3310 | 8 m | Material: Deli POM Chain Plate |
6 | Power head | YCT-A | 1 unit | Hing Tat 1.5 KW Power Enhancement |
7 | Conveyor rack | Two-way adjustable | 8 m | Material :304 stainless steel |
8 | Conveyor Belt Guard | Two-way biaxial | 8 m | Material: Stainless steel |
9 | Filling head landing gear | 8 stations | 1 | Material: Bolui 304 Stainless Steel |
10 | Electrical components | VB5N Shinzo | 1 set | Letter |
11 | Pressure gauges | 1MPA | 1 set | Chimei plexiglass |
12 | Filling door glass | 5MM | 1 set | Chimei plexiglass |
13 | Rehydration pump | Y 90S-2 | 1 unit | HK $1.5 KW |
14 | Photoelectric sensor | E3F-DS30C4 | 2 sets | Celibate |
15 | Bottle holder | MAL-25X125 | 2 sets | MPA 0.1-1 |
16 | Security Filter | 5*20 | 1 unit | Material: Bona stainless steel |
17 | Distribution box | Supporting | 1 unit | Stainless Steel |
Product advantages
● High accuracy: average error 10 ml.
● High speed: filling 2000-2500 bottle/ hours, stepless speed change.
● Capacity: filling capacity can be adjusted arbitrarily between 0.5-25 liters.
● Wide range: can be used for a variety of special-shaped bottles, and the change of bottle type adjustment is convenient and fast.
● nNo liquid loss: filling head deep into the bottle mouth filling, no water, no overflow.
● Bottle types: track and filling head drop position adjustable, not limited by bottle height, short.
● Automatic liquid level: the liquid level control adopts the computer panel preset control device to control the liquid level stability.
● Electric adjustment: electric synchronous continuous stepless adjustment quantitative, liquid crystal digital display accurate display.
● Soft start: when boot, the machine from low speed to set speed, no rigid impulse, so will not break the bottle injury machine.
 |  |  |  |
