Raker

Raker

SHANDONG JUYUAN NEW MATERIALS TECHNOLOGY CO., LTD.

The agricultural Raker for small tractors are mainly used to improve the quality of land preparation for small implements, reduce the number of operating layers, and meet agricultural requirements. Two sets of notched harrow blades and two sets of disc harrow blades are installed on the two additional crossbeams under the square frame frame. There are adjustment holes on the frame, and the rear end of the frame has an agricultural implement connection structure and a handrail. This harrow can adapt to soils of different geology and has a relatively ideal operating effect.

型号Model

R-4

R-5

R-6

R-7

R-8

R-9

工作幅宽Width of scraper (mm)

1200

1500

1800

2100

2400

2600

整机重量Weight (kg)

120

140

160

180

200

220

配套马力Tractor power (hp)

20

30

40

50

60

70

挂接方式Mounted cat

三点悬挂Three-point mounted
